Make: NATIONAL OILWELL – National Oilwell Power Slush Pump
Model: 14P220
Maximum Liner Size: 9 Inch
Stroke: 14 Inch
Rated Maximum Input: 2200 HP at 105 SPM
Rated Maximum Output: 1980 HP at 105 SPM
Gear Ratio: 3.989
Hydrostatic Test: 11250 PSI
Manufacturer: National Oilwell – Houston, Texas, USA
Type: Power Slush Pump – Triplex Mud Pump For Oil Well Drilling
Make: NOV – NATIONAL OILWELL VARCO NORWAY AS
Equipment: 321-CE121/VX121 Cement Dust Cycl/Col – Cement Dust Cyclone / Collector
Year Built: 2010
Model No: DP46
Design Pressure: 66 psi
Max Operating Pressure: 60 psi
Design Temperature: -10° C / +50° C
Total Volume: 2,0 m3 – 2.0 Cubic Meter
Max Operating Volume: 1,8 m3 – 1.8 Cubic Meter
Max Specific Gravity: 2,16 kg/dm3
Classification Society: ABS – American Bureau of Shipping
Make: NOV – National Oilwell Varco AS – N-4604 Kristiansand, Norway
Model: OC1891PS02
Year: 2011
SWL / Working Radius: 9t-22,3m – 9 Ton Safe Working Load at 22.3 Meter Radius
Total Dry Weight: 29.500 kg – 29.5 Ton
Type: Offshore Pedestal Crane – OC Series – OC1891PS02
Make: NOV – NATIONAL OILWELL VARCO – National Oilwell
Equipment: Delivery Module – Discharge Module – Fluid End Module – Discharge Manifold
Model: 14P220 – For 14P220 Power Slush Pump
Pressure Rating: 7500 PSI Working Pressure
Condition: NEVER USED – NEW
Compatibility: Direct Fit For National Oilwell 14P220 – All 14P220 Models – Serial 11056-H, 11097-H
Material: High Strength Forged Alloy Steel – High Pressure Fluid End Module
Make: NOV – NATIONAL OILWELL NORWAY AS
Equipment: CONDUCTOR TENSIONER – Conductor Tensioner For Offshore Drilling
Project No: V4504 – NOV Project V4504
Year Built: 2010
Model No: V4504-D1171-G0001
Make: NOV – NATIONAL OILWELL VARCO – Varco
Equipment: IRON ROUGHNECK – Automated Pipe Handling – Drilling Rig Iron Roughneck
Model: AR-4500 Iron Roughneck
Gross Weight: 14500 LBS / 6577 Kg – 6.5 Ton
Capacity Max Torque: 100,000 FT LBS Make-Up – 100K FT LBS
Size Ranges: 3 1/2 – 9 3/4 Inch OD – 3.5″ to 9.75″ Outer Diameter Pipe Handling
Utility Requirements Hydraulic: 2500 PSIG at 45 USGPM
Utility Requirements Electrical: See Service Manual
Origin: NOV Varco
